DA 1260 Built-Under Rangehood

Product Description

DA 1260 Built-Under Rangehood

Construction Type

-         Built in rangehood

Design

-         Colour Stainless steel

Operating modes

-         Type of air guide Convertible

-         Active charcoal filter (order separately) DKF18-1

User convenience

-         Mechanical controls

-         Slide switch

-         Power levels (number without Booster level) 3

-         Booster level

Cleaning convenience

-         Easy-to-clean canopy interior – CleanCover

-         Filter system

-         Number of dishwasher safe stainless steel grease filters 2

Lighting

-         LED

-         Light intensity in Lx 330

-         Colour temperature in K 3000

Fan

-         Single-action fan

-         AC motor

Air throughput with max. duct diameter in extraction mode (not for external version)

-         Air throughput in Level 1 (m³/h) 275

-         Air throughput in Level 2 (m³/h) 315

-         Air throughput in Level 3 (m³/h) 355

-         Air throughput in Booster level (m³/h) 545

-         Sound power in Level 1 (dB(A) re 1 pW) 57

-         Sound power in Level 2 (dB(A) re 1 pW) 60

-         Sound power in Level 3 (dB(A) re 1 pW) 64

-         Sound power in Booster level (dB(A) re 1 pW) 74

-         Sound pressure in Level 1 (dB(A) re 20 µPa) 43

-         Sound pressure in Level 2 (dB(A) re 20 µPa) 47

-         Sound pressure in Level 3 (dB(A) re 20 µPa) 50

-         Sound pressure in Booster level (dB(A) re 20 µPa) 60

Air throughput in recirculation mode

-         Air throughput in Level 1 (m³/h) 165

-         Air throughput in Level 2 (m³/h) 180

-         Air throughput in Level 3 (m³/h) 195

-         Air throughput in Booster level (m³/h) 220

-         Sound power in Level 1 (dB(A) re 1 pW) 71

-         Sound power in Level 2 (dB(A) re 1 pW) 72

-         Sound power in Level 3 (dB(A) re 1 pW) 73

-         Sound power in Booster level (dB(A) re 1 pW) 75

-         Sound pressure in Level 1 (dB(A) re 20 µPa) 57

-         Sound pressure in Level 2 (dB(A) re 20 µPa) 58

-         Sound pressure in Level 3 (dB(A) re 20 µPa) 59

-         Sound power in Booster level (dB(A) re 1 pW) 62

Technical data

-         Canopy width in mm 598

-         Canopy height in mm 125

-         Canopy depth in mm 500

-         Minimum height above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm 650

-         Net weight in kg 11.2

-         Length of supply lead in m 1.5

-         Standard plug fitted

-         Total rated load in kW 0.24

-         Voltage in V 230

-         Fuse rating in A 10

-         Number of phases 1

Installation notes

-         Extraction ducting connection at top

-         Diameter of extraction ducting connection in mm 150

-         Fitting template

Standard accessories

-         Non-return flap

-         Deflector for recirculation

-         Adapter to reduce ducting diameter from 150 mm to 125 mm
