DHL895DAU - 86cm Series 8 Integrated Rangehood

Product Description

DHL895DAU - 86cm Series 8 Integrated Rangehood

KEY FEATURES

-           Extraction rate: at 800 m3/h, it quickly ensures optimal kitchen air quality.

-           LED lighting: for perfect, energy-efficient illumination of the cooktop.

-           Intensive speed setting with reset: automatically resets the hood to regular speed setting after 6 min.

-           Especially quiet: high performance at just 64 dB.

Design & Innovation

-           86 cm Fully integrated rangehood

-           Appliance colour: Stainless steel

Power and Mode of Operation

-           3 power settings plus intensive setting

-           Extraction rate according to EN 61591 ø 15 cm:

-           max. Normal use 610 m³/h

-           Intensive 800 m³/h

-           Ducted and recirculated-air operation

-           Accessories required for recirculation mode: CleanAir Module

-           Electronic controls with green Electronic display

-           EcoSilence BLDC brushless motor

-           Rim ventilation

-           Noise min./max. Normal Level: 41/64 dB

-           Noise max. Intensive setting: 70 dB

-           Power rating: 172 W

Comfort & Convenience

-           Dishwasher safe metal grease filters

-           Intensive operation automatic revert - 6min

-           Automatic run on for Automatic run on time - 30 min

-           2 x 1 Watt LED lights

-           Saturation display for filters

Technical Information

-           Dimensions exhaust air (HxWxD): 418-418 x 860 x 282 mm

-           Dimensions recirculating (HxWxD): 418-418 x 860 x 282 mm

-           Diameter pipe Ø 150 mm (Ø 120 mm enclosed)

-           Electrical cable length 1.5 m

Construction type

-           Diameter of air outlet (mm) 120 / 150 mm

-           Colour Stainless steel

-           Grease filter material Washable aluminium

-           Grease filter type Kassette

-           Installation typology Built-in

-           Material of the body Stainless steel

-           Motor location Integrated motor in hood body

-           Number of motors 1

-           Operating Mode Convertible

-           Typology Traditional

Connection

-           Connection rating (W) 172 W

-           Length electrical supply cord (cm) 150 cm

-           Frequency (Hz) 50 Hz

-           Total power of the lamps (W) 2 W

-           Total power of the motors (W) 170 W

-           Voltage (V) 220-240 V
